LIONLED Outdoor Street Light Pole LED Display Waterproof P2.5 For City Advertising
Pixel Pitch: 2.5mm
Module Size: 320mm×160mm/192mm×192mm
Cabinet Size: 960mm×640mm/960mm×576mm/Customized
Pixel Density: 160000pixels/m2
Brightness : 6000-10000cd/m2
Scan: 1/16
Refresh Rate: 3840Hz
Color: Full color
Life Span: 100000 hours
Warranty: 6 Years
Certificate: CE,FCC,ROHS,UL,PSE
Supplier Type: Original manufacturer, ODM,OEM
Media Available: Datasheet, Photo, EDA/CAD Models, Other
Product advantages
Product parameters
| Pixel Pitch(mm) | 2.5 | 4 | 5 | 6.67 | 8 | 3 | 6 |
| LED Type | SMD/GOB | ||||||
| Pixel Density/m² | 160000 | 62500 | 40000 | 22500 | 15625 | 111111 | 27777 |
| Brightness(cd/m²) | 6000-10000 | ||||||
| Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 | 192*192 | 192*192 |
| Scan | 1/16 | 1/10 | 1/8 | 1/6 | 1/3 | 1/16 | 1/4 |
| Cabinet Size(mm) | 960*640/customized | 960*576/customized | |||||
| Cabinet Material | Waterproof Iron/Aluminum | ||||||
| Cabinet Weight | 30~40kg/sqm | ||||||
| Viewing Angle | H:140°V:140° | ||||||
| Color Temperature | 6000-9500K | ||||||
| Gray Scale | 14-16bit | ||||||
| Refresh Rate | ≥1920Hz | ||||||
| Ingress Protection | IP65-68 | ||||||
| Operating Temperature | -20℃~60℃ | ||||||
| Operating Humidity | 10%~65%RH | ||||||
| Input Voltage | AC220V/110V±15%47-64Hz | ||||||
| NTBF | ≥50000 hours | ||||||
| Life Time | 100000 hours | ||||||
| Max Power Consumption | 700-850W/m² | ||||||
| Average Power Consumption | 350-450W/m² | ||||||
Product Features
Support GOB And SMD Technology
Multiple sizes to choose from, there's one for you!
6 Years Warranty. Adopting high quality configuration, low power consumption and stable brightness at the same time
Brightness can be controlled according to night and day
Good resistance to high and low temperatures, can work stably under different climatic conditions.
Structural design is robust and durable, with strong wind resistance and shock resistance, and can work stably in bad weather.
